Recent Millennium Industrial Projects



Industrial Vacuum ReceiverCENTRAL VACUUM SYSTEMS FOR PHARMACEUTICAL COMPANY
Millennium provided two independent Central Vacuum Systems for an Intermediate Bulk Pharmaceutical Company in Illinois. Equipment included Vacuum Receivers, Vacuum Blower Package, Central Vac cleaning tools and inlet valves/fittings. Scope included Equipment layout drawings, Mechanical Installation, and Project Management.

100,000 CFM DUST COLLECTION SYSTEM FOR COPPER REFINING COMPANY
Millennium provided complete Turnkey Dust Collection System for Copper Refining Company in the Midwest. Project scope included custom fabricated Dust Collection System rated for approximately 100,000 cfm and approximately 400 degree F. System captured dust from two (2) Furnace stacks. Equipment included a six (6) module dust collector with high temp. rated filter bags/cages, rotary airlocks, level controls, fan, exhaust stack, platforms, stairs, ladders, ductwork, structural steel supports, dampers, compressed air system, and Electrical control panel. Millennium provided Engineering Services, Equipment Sizing, Equipment Layout Drawings, Mechanical and Electrical Installation along with Project Management Services.

VACUUM BELT FILTER DRYER / SCREW CONVEYORS FOR CHEMICAL PLANT IN ST. LOUIS
Millennium was the acting Sales Rep for a Principal while supplying two (2) Vacuum Belt Filters for a Clay Drying application to a local Clay Processing Plant. Millennium also supplied four 316 Stainless Steel Screw Conveyors for conveying product from Belt Filter discharge to downstream equipment. Millennium included equipment layout drawings as part of scope.

Bag Dump / Conveying SystemSTARCH BAG DUMP / SIFTING / CONVEYING / METERING SYSTEM FOR PHARMACEUTICAL COMPANY
Millennium provided complete Turnkey Bag Dump / Conveying System for a Midwest Pharmaceutical Plant. Fifty pound (50 lb.) bags of Starch were opened, dumped, sifted, conveyed, and metered into drums where it was weighed. Scope of Supply included Stainless Steel Bag Dump Station with integral dust collection, connected pneumatic Bag Compactor for disposing of empty 50 lb. bags, single deck Stainless Steel Sifter, Vacuum Conveying System with Vacuum Receiver / Blower / Rotary Valve, Platform Scale, and Electrical Control Panel. Millennium Project Services included Engineering, Sizing, Equipment Layout Drawings, Mechanical Installation, Project Management, and Start-up.

BULK FLOUR SYSTEM FOR BAKERY IN CALIFORNIA
Millennium was the acting Sales Rep organization for a Principal while supplying a Bulk Flour System for a Bakery in California. Scope of supply included Bulk Flour Silos for Truck Receiving / Unloading, Rotary Valves, Bin Vents, Pneumatic Conveying, Sifting, and Scale Hopper modifications/instrumentation. System included Electrical and Mechanical Installation, Project Management, Start-up and Training.

AUTOMATED MINOR / MICRO INGREDIENT BATCHING SYSTEM FOR BAKERY ON WEST COAST
Millennium was the acting Sales Rep organization for a Principal while supplying a thirteen (13) ingredient automated scaling system to batch ingredients into customer supplied buckets. A typical batch consisted of between 1 and 7 ingredients with weights ranging from 0.3 pounds to 110 pounds based on a certain recipe. Scope of supply included Minor / Micro Ingredient Storage Bins, vibratory metering feeders, Bulk Bag Unloading Station, Accumulating Conveyor, Platform Scale, Central Dust Collection, Support Structure with Platform Access, Vacuum Hoist bag lifting system, Electrical Controls, Mechanical and Electrical Installation.

Dust Collector SystemDUST COLLECTION ENGINEERING STUDY / DESIGN FOR PHARMACEUTICAL COMPANY
Millennium provided Engineering Services including system sizing, layout drawings, and scope of equipment supply for three Process Areas of the Plant. Millennium was also awarded Purchase Orders for the supply of these complete Dust Collection Systems. Equipment scope included Dust Collectors, Quick-Connect Stainless Ductwork / Supports, Rotary Airlocks, Exhaust Fans, Stacks, Timer Boards and Instrumentation. Millennium also provided Project Management and Mechanical Installation Services.

BULK FLOUR SYSTEM FOR MAJOR INDIANA FOOD COMPANY FOR PANCAKE MIX LINE
Millennium was the acting Sales Rep organization for a Principal while supplying a Bulk Flour delivery system for customers new pancake mix line. Scope of supply included modifications to existing Bulk Flour System, Conveying and Sifting System, New Scale Hopper, Screw Conveyor, Structural Supports, and Electrical Controls.

PIAB VACUUM CONVEYING SYSTEM FOR GUN POWDER CONVEYING/CHARGING SYSTEM
Millennium supplied twenty (20) Piab Vacuum Conveyors to convey gun powder from Powder Keg Box to Rimfire Ammunition Charging Unit. Scope of supply included Piab Vacuum Conveyors, Custom Feed Wands, Stainless Steel piping / couplings / elbows, and Custom Control System.

GENERAL KINEMATICS VIBRATING FEEDER
Supplied a Heavy Duty, Fixed Rate Para-Mount II Vibrating Feeder for handling crushed anode butts for an Aluminum Refinery in Southern Missouri. Unit is Floor Mounted under Crusher, and designed to handle 60 TPH of petroleum coke anode butts (4” lumps) at 55-60 PCF.

SCREW CONVEYOR
Supplied Food Grade Sanitary Reversing Screw Conveyor to Nestle Beverage for handling Coffee Creamer. Unit is designed to move 600 CFH of Powder Coffee Creamer, 24-48 PCF, horizontal. Entire Screw is 304 SS with polished 150 grit finish.
